Product Description
Basic Info
- Model NO.: 4YZ-6(CF808)
- Application: Rice, Corn, Wheat, Soybean
- Harvest method: Cutting
- Transmission: Hard Shaft
- Certification: ISO9001:2008
- Condition: New
- Switchboard Weight: 9500kg
- Engine Power: 180HP
- Trademark: YRX
- Specification: 8600*4200*3800mm
- HS Code: 8433510001
- Type: Horizontal Cut Harvester
- Power Source: Diesel
- Drive Type: Gear Drive
- Portable Harvester Type: Side Hanging Type
- Color: Green
- Application Field: Agriculture, Livestock, Aquaculture
- Cutting Width: 1300mm
- Feed Capacity: 6kg/S
- Transport Package: Frame
- Origin: China
Product Description
CF808(4YZ-6) Wheeled Combine Harvester
![Reliable Wheeled Type Corn Combine Harvester with Low Price]()
![Reliable Wheeled Type Corn Combine Harvester with Low Price]()
![Reliable Wheeled Type Corn Combine Harvester with Low Price]()
![Reliable Wheeled Type Corn Combine Harvester with Low Price]()
Product overview:
CF808 is a harvester designed especially for corn, its performance is far better than other imported foreign brands, quality and performance is well ahead of similar type in China. It has high performance-to-price ratio and the coast for operation and maintenance is much lower than foreign brands. Characteristics1. The world-class longitudinal axial flow threshing and separation structure, axial roller adopts the blade feeding, vertical oblique, concave plate clearance can be adjusted, soft threshing, thorough separation, low crushing rate. Its threshing performance is far ahead of other foreign brands, and have 10 different drum rotational speed, greatly enhance threshing and separation performance for different crops;2. The new design of open-type main frame make the repair and maintenance of the axial flow roller more convenient;3. Special straw crushing and spilling structure, with high refinement and well-distributed scattering work, meet the demand of straw returned to field and increase soil organic matter and fertility;4. Using Yuchai turbocharged six-cylinder engine, power up to 180HP, fully meet the demand of harvesting work, which is ahead of other foreign brands;5. Front axle adopt fission structure, can realize unilateral brake, with strong adaptability, flexible steering, small turning radius, convenient maintenance, solid and reliable, etc;6. Connecting the cutting table and bridge, using reinforced bridge at the same time. The cutting table is free to remove, which can also be changed according to different requirement, saving time for transportation and maintenance of the cutting table;7. Adopting world-class remaining processing system, make the corn which is not cleanly threshed back to the roller for re-threshing, with better threshing performance and low losses;8. Using 5m³big grain tank and hydraulic unloading system, with 4.3 m lengthening unloading grain tube, whose height is 4.2 m, makes unloading work more convenient, greatly improve the machine's field adaptability, can realize unloading together with harvest, improve work efficiency;9. The world-class double mesh sieve, cleaning area reaches 4 m2, match with fan of infinitely variable speed. Cleaning air volume can be adjusted, stable wind and thorough cleaning, improves the cleanliness;10. With world-class man-machine engineering design for circular arc cabin, the driving view is better, and the ride is more comfortable. Technical Parameters| Model | 4YZ-6(CF808) |
| Structural Style | Wheeled self-propelled full feeding |
| Assorted Engine | Specification | YC6A180Z-T21(A7AS4) |
| Rated output kW | 130 |
| Rated RPM r/min | 2300 |
| Measurement(L*W*H) mm | | 8600×4200×3800 |
| Machine Weight kg | 9500 |
| Harvest Rows | 6 |
| Applicable spacing range mm | 600~700 |
| Minimum Ground Clearance mm | 540 |
| Productivity per working hour hm2/h | 1.0~1.6 |
| Stalk pulled roller type | cone spiral with knife roller |
| Snapping plate type | steel adjustable |
| Threshing drum | Type | Rasp Bar Debugging/Spike tooth |
| Size(diameter*length) mm | 650×2950 |
| Quantity | 1 |
| Intaglio pattern | Grid format/Comb-type |
| Screen Width mm | 1300 |
| Gearbox Type | Hydraulic continuously variable shift / mechanical transmission |
| Tread | Front wheel mm | 2500 |
| Rear wheel mm | 2800 |
| Tire Size | Front wheel | 12-18 |
| Rear wheel | 28L-6 |
| Stalk Chopper Type | Flail |
