Technical Advantages of YT-20
l According to the different models, It can process diameter of 8-28mm reinforcing steel bar, support Bi-directional bending and also can bend special–shaped stirrup.
l Has independent cut function, one steel bar can complete multiple of different graphics, to avoid the repeated loading.
l Use high-end servo motor with super power, self-checking and self-repairing, which is stable and reliable.
l Real time control system, according to the size of stirrup, it can adjust the rebar running speed, bending speed and bending angle during operation.
l Smart step speed control, auto controls the rebar running speed and bending speed separately, and make sure larger size stirrup will not be deformation by inertial fling.
l Set standard picture base, which can save and use the pictures automatically.
Technical Parameters of YT-20
YT-20 CNC Rebar Bending Machine | |||
Model# | YT-20 | Reinforcement Length | 1000-12000mm |
Bending Bar Diameter | Φ12-Φ20mm | Length Tolerance | ±1mm |
Bending Angle | 1°-180° | Angle Tolerance | ±1° |
Bending Direction | Bi-direction | Equipment Dimension (mm) | 3300×1311×2080 |
Max Pulling Speed | 60m/min | Rated Power | 28KW |
