Product Details

High quality rake Sr180

There are traction type, suspension type and other types, the working parts are a row of lateral parallel circular shape or spiral shaped spring teeth.When working, the rake spring tooth tip touches the ground, and the grass cut by the mower is wrapped into a horizontal blade (that is, the blade is perpendicular to the moving direction of the machine).Because the grass is tight, not conducive to dry, and mixed, not tidy, not conducive to the follow-up work.Operation speed is also low, generally 4 ~ 5 km/h.The size of the strip can be controlled by hand and is usually used in natural pastures with low yields.



Model	9LTS-3		9LTS-4		9LTS-4.8		9LTS-4.8	9LTS-6	9LTS-7	9LTS-8	9LTS-9	9LTS-9.5
Weight (kg)	255		375		445		850	1000	1100	1250	1350	1450
Working Speed (km/h)	5-12
Matched Power (kw)	15-29.4		25.7-44.1		29.4-52			≧36.7
Working  Width (mm)	3000			4000		4800	4800	6000	7000	8000	9000	9500
Number of Finger Disc (pcs)	4			6		8	8	9	10	11	12	13
Diameter of Finger Disc (m)	1.46
Grass Strip’s Width	0.9-1.2	1-1.5
Linkage	Three Point Mounted						Trailed













Weifang Binhai Group Work Win Supply Chain Co., Ltd is a leading manufacturer and provider of total integrated supply chain solutions. We offer the best chemical products for the orders.

Weifang Binhai Group Work Win Supply Chain Co., Ltd is a leading manufacturer and provider of total integrated supply chain solutions. We offer the best chemical products for the orders.

We have a multilingual team, and many big branch factories. A regional market presence-including southeast Asia, Indonesia, Russia, Spain, Chile, Brasil, Australia etc.

Group Work Win strives to build a long term relationships by providing our customers with continuous and reactive support. We aim to supply better quality products and after-sales service.




Contact information

Bing Zhou (Sales Manager)

E-mail: bing@groupworkwin.com

Whatsapp/wechat:+86 13963692050

Website: www.estmachine.com

Weifang Binhai Group Work Win Co., Ltd.









Q1: How about your company?

A1: We are a leading manufacturer and provider of total integrated supply chain solutions for agricultural machinery.

Q2: What is the MOQ?

A2: Normally the MOQ is one set. There are some exceptions to this requirement because of the type of machines.

Q3: What is the delivery time?

A3: 15-20 working days after payment.

Q4: What about the package?

A4: Iron frame or iron crate.

Q5: Can I put my brand name on your agricultural machines instead of your brand name?

A5: Yes. We could do OEM/OBM.

Q6: What about the payment terms?

A6: T/T. We also can accept other payment terms.

Q7: Can we mix different models together?

A7: Sure. We can offer different agricultural equipments, you could mix different products or models in 20FT or 40FT container but in order to make the best use of container room, usually we advise you to check the size of the machines.
