Product Details

Aircraft Frame
Dimension	1436*1436*550 mm（arm unfolded, without propellers） 710*820*550 mm（arm folded, without propellers）
Diagonal Wheelbase	1300 mm
Flight Parameters
Total Weight	10.5 kg（without battery）  23.5 kg（with battery, Full Loaded）
Standard Take-off Weight	23.5 kg
Max Take-off Weight	25 kg
Hovering Time	10 min （23.5kg take-off weight）* 25 min （13.5kg take-off weight） *
Max Operating Speed	8 m/s *
Max Flying Speed	10 m/s *
Recommended Operating Temperature	-10℃~40℃
Spray System
Liquid Tank Volume	10 L
Number of Nozzle	4
Spraying Span	3.5-4m
Theoretical Operating Efficiency	200,000㎡/day   (8hs, 6 sets of batteries)
Max Spraying Speed	1.6L / min
Ground Controller
Max Transmission Range	1000 m  (Unobstructed, Free of Interference)**


*The Flight parameters are for reference only. Different natural conditions may affect the actual flight situation.
*The Transmission Range may be influenced by varied conditions. Choose open area without high buildings as the flight area.
