Product Details

1.Quick Details
Place of Origin:Henan, China (Mainland)
Brand Name:Mercury-tech
Model Number:LDM-25XY
Accuracy:0.001
Laser Type:Semiconductor
Application:Laser diameter measuring
  Working voltage:220V±10%
2.Packaging & Delivery

Packaging Details	Carton or Wooden Box
Delivery Time	In three days after getting your payment



3. Technical parameters
Model       Measuring Range    Differentiation             Accuracy
LDM-50XY      0.1-50mm                  0.001      ±0.02%×(Reading)±0.002mm

Model	LDM-25XY	LDM-50XY	LDM-60XY	LDM-100XY
Measuring Range	0.2-20mm	0.2-45mm	0.2-55mm	0.2-95mm
Accuracy	±0.001mm	±0.002mm	±0.002mm	±0.002mm
Repeatability	0.5μm	0.5μm	0.5μm	0.5μm
Resolution	0.001mm	0.001mm	0.001mm	0.001mm
Dimension	420x400x85mm	420x400x85mm	380x380x60mm	590x620x97mm
Units of Measurement	mm	mm	mm	mm
Power	~220V±15%,50~60HZ
Temperature	-10~40°C
Humidity	<85%RH
Gauge Head Serial I/O	Standard: RS485     Options: RS232 / USB
Communication Protocol	Modbus / Profibus
Presets	Diameter, +Tol, -Tol, Alarm Setting
Ovality Measurement	√	√	√	√
Transparent Measurement	Option	Option	Option	Option
Control Output
Serial I/O	RS485
Analogues Output	16 bit ± 10V DC Output
Relay Output	2 Volt Free ( Upper Tolerance, Lower Tolerance )



4. The performance indicators:

Measurement: Laser scanning
Laser: Visible red semiconductor laser
Laser output power: <2mW
Operating voltage: ~ 220V ± 15% 50 - 60Hz
Operating temperature: -10 ~ 40 °C
Humidity: <85% RH
Work mode: continuous
Power consumption: <30W
Dimensions:
Measuring head: 372mm×360mm×60mm

5. The Device with the following Characteristics
1. Can be connected PLC, industrial computer.
2. RROFIBUS-DP can be allocated and MODBUS converter and PLC, IPC Connect.
3. Can be equipped remote controller DDC-3, DDC-5, on the extruder and automatic feedback control to control the tolerance, improve product quality, reducing consumption.
