Product Details

Product Introduction

DLX-850G series 10/100M/1000M Ethernet Fiber Media Converter is a kind of stand-alone type media converter that includes one main board of fiber converter and different kinds shell and can be centralized control by chassis. It is used to translate the data between 10Base-T twisted-pair and 10Base-FL optical cable or between 100Base-TX twisted-pair and 100Base-FX optical cable or between 1000Base-T twisted-pair and 1000Base-FX optical cable. And this equipment can extend the transmission distance from 100m to 100KM via the quick Ethernet Fiber Optical. It adapts to the connection of optical fiber of backbone and is a kind 1000M Ethernet Fiber Media Converter of fine quality and low price. It is primarily used in broadband WAN established by data network operators as Telecast, Netcom, Unicom, or industrial broadband industrial private network of government, finance, oil, police, force, railway, power, transportation, education, etc

　

Product Feature

●      Fully compatible with IEEE 802.3,802.3µ,802.3z ,802.3ab Standard, Cisco, and 3COM equipment or other similar kind  equipment

●      Selectable optical link-loss alarm

●      Supports 10/100M/1000M,full/half duplex  auto-negotiation

●      Indicators for Power Supply, Ethernet rate, Ethernet  interface mode, Ethernet interface status and Optic-link

●      Supports super jumbo frame and over-sized packets up  to 1920Bytes

●      Supply one RJ-45 electrical port

●      Supply LFP function optional

●      Supports transmission distance up to 100km

●      Auto-negotiate and Auto-cross to  NIC/HUB and MDI/MDI-X

●      Advanced optical and electronic integration mechanism  can supports good optic characteristic and electrical  characteristic, and can ensure the high quality and excellent  reliability of data transmit

●      Auto restart when crashed, super heat radiation, super  low power consumption(<1.5W)

●      Main board adapts multi layer structure of circuit  board, possess excellent reliability and good anti-jamming feature

●      Average time of fault free is more  than 50,000hours,meet the standard of telecommunication operation

●      Supports hot-swappable, 12V DC and the Local end  support rack mounted

　

Technologies reference

●      Operating  temperature: 0℃-50℃

●      Storage  temperature: -40℃-70℃

●      Environment  humidity: 5-90%(non-condensing)

●      Power  parameters:    100V~260V AC  (Inner  power supply)  or 5V DC  (External  power supply)

●      Dimension:  107mm x 72mm x 28mm
