Product Details

Main Features:
●With DVR function to record every beautiful moment
●Built-in dual receiver for best reception
●Dual buffered AV outputs avoid interference from the 2.4GHz R/C radios
●One key automatic signal search greatly simplified the operation
● AV receiver with diversity inputs
● Support Chinese and English menu
● Small, lightweight, and durable
● 5 bands and total 40 channels for more frequency choices
● Built-in battery, it is easy to carry and use outdoor
● Work status OSD display: always be aware of the device working condition.


Specifications:
-Built-in 5.8GHz dual diversity receiver
-Built-in 2CH 5.8GHz AV output and 1CH AV input
-Built-in high-performance LiPo Battery: 2000mAh 7.4V
-Work status OSD display: RSSI indication, battery indicator, channel indication
-Format: JPEG, AVI
-Screen size: 7 inch
-Screen type: TFT LCD Screen, LED backlight
-Resolution: 800 x 480
-Brightness: 600cd/square meter
-View angle: 140/120degree ( Horizontal / Vertical )
-Working voltage: DC 7 - 16V
-Power consumption: max 650mA 12V
-Battery charging current: max 850mA 12V
-Charging time: 2h
-Operation time: 2 - 3h
-Working temperature: -10 Deg.C - 65 Deg.C
-Connector: RP-SMA female ( outer needle )
-Antennas connectors: RP-SMA male ( inner hole )
-Support up to 32G, C10 SD card


Package includes:
1 * LCD5802D Monitor
